Tektronix 80E10
50 GHz True differential TDR Sampling Module
Rent or Lease • Buy Used From $10,000
The 80E10 is a dual channel Time Domain Reflectometry (TDR) sampling module, providing up to 12 ps incident and 15 ps reflected rise time. Each channel of the module is capable of generating a fast step for use in TDR mode and the acquisition portion of the sampling module monitors the incident step and any reflected energy. The polarity of each channel's step can be selected independently. This allows for differential or common-mode TDR or S-parameters testing of two coupled lines, in addition to the independent testing of isolated lines. The independent step generation for each channel allows true differential measurements, which ensures measurement accuracy for differential devices.
Read More
- Configurations
- Resources
--
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
NO/VER-Wrist strap kit. (10 or more $16/ea)
Qty: 1 -
LAB/VER-2.4mm/1.85mm S Male to 2.92mm (K) Female Adapter
Qty: 2 -
Transit case with anti-static foam. Combination of part numbers 016200000 (hard case) and 004545500 foam insert. (This is a custom made case from streamline)
Qty: 1 -
LAB/VER-SMA 50 Ohm Term w/ Beaded Chain
Qty: 2 -
NO/VER-Guide Rail Kit (2 guide rails, 4 flathead 4-40 screws)
Qty: 1 -
SW-063-3747-10 8000 Product Documentation, 071-1386-07 Read First, 85W-14243-0 Release Notes
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
Specs
