Keysight (Formerly Agilent) N5241A-200
2-port, 13.5 GHz PNA-X Network Analyzer, 3.5 mm (m)
Rent or Lease
The Keysight (formerly Agilent) N5241A-200 is a 13.5 GHz PNA-X Microwave Network Analyzer. The N5241A-200 boasts a variety of applications like the measurement of S-Parameters, Noise Figure, Gain Compression, X-Parameters, Balance Measurements, Pulsed RF, and IMD.
Key Specifications of the N5241A-200:
- 10 MHz to 13.5 GHz
- 2- or 4-ports with two built-in sources
- 132 dB system and 130 dB receiver dynamic range, 32,001 points, 32 channels, 5 MHz IF bandwidth
- High output power ( 18 dBm), low harmonics (-60 dBc) and a wide power sweep range (38 dB)
- Best dynamic accuracy: 0.1 dB compression with 13 dBm input power at the receiver
- Low noise floor of -114 dBm at 10 Hz IF bandwidth
With its wide range of applications and modern technologies, the N5241A-200 offers faster test times, reduced equipment count, increased operator productivity, and reduced re-testing, and cable swaps. If you are looking to rent or lease the Keysight (formerly Agilent) N5241A-200, request a quote today at TRS-RenTelco.
- Configurations
- Resources
021, 025, 080, 200, 219, 224
See Configuration Details
-
021
Add Pulse Modulator To Internal First Source
-
025
Internal Pulse Generators, Add 4
-
080
Frequency Offset Measurements
-
200
2 Ports, Single Source
-
219
Add Extended Power Range And Bias-tees To 2 Port Analyzer
-
224
Add Internal Second Source, Combiner And Mechanical Switches To 2-port Analyzer
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
LAB/VER-SMA 50 OHM Terminator (Mouser (Amphenol) 523-132360 checked by David Y. OK)
Qty: 3 -
NO/VER-Wrench - Torque 8 in/lb, 20 mm open end
Qty: 1 -
NO/VER cable guard
Qty: 2 -
LAB/VER-RF Cable Front/REAR Panel Jumper
Qty: 9 -
NO/VER-6 HOLE HANDLE KIT,GREY see #5023-1399 for sub
Qty: 1 -
NO/VER-Right angle power cord
Qty: 1 -
NO/VER-Keyboard-USB
Qty: 1 -
NO/VER- USB OPT MOUSE (CDW PN# 2086051 @ $7.75/ea)
Qty: 1 -
SW-IO Libraries Suite (v18.2.27115)
Qty: 1 -
Void- SW-5969-5826 VNA and PNA Intuilink, E8356-10001 PNA Documentation 12/23/2015, 82357-90002 Manual 82357-90104 Getting Started. N5242-90019 OPT H85 USER AND SVC GUIDE E8356-90001 Installation and Quick Start Guide Edition 2 Aug 2017
Qty: 1
