Keysight (Formerly Agilent) N5230C-245
4-port, 20 GHz PNA-L Network Analyzer, 3.5 mm (m)
On Order: 0
Warranty: 12 Months
Buy New
The Keysight N5230C-245 is a PNA-L Microwave Network Analyzer used for general purpose analysis. The N5230C-245 comes with an 8.4-inch touch screen, a simple interface that has pull down menus, and ergonomic hard, and soft keys among other features.
Key Specifications of the N5230C-245:
- 108 dB of dynamic range and <0.006 dB trace noise
- Having 4 to 9 ?sec/point measurement speed, 32 channels, 20,001 points
- TRL/LRM calibration, on-wafer, in-fixture, and waveguide measurements
- 300 kHz to 6/13.5/20 GHz and 10 MHz to 20/40/50 GHz
- 2- or 4- ports with two built-in sources
- 110 dB system and 122 dB receiver dynamic range, 32,001 points, 32 channels
- < .006 dB rms (Option 22x)
If you are looking for a new or well-maintained used Keysight (formerly Agilent) N5230C-245 PNA-L network analyzer for rent or lease, contact us or request a quote today.
- Configurations
- Resources
010, 080, 245
See Configuration Details
-
010
Time Domain For 13.5, 20, 40, And 50 Ghz Pna-L
-
080
Frequency Offset Mode
-
245
300 Khz To 20 Ghz, 4 Port, Configurable Test Set And Extended Power Range
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
NO/VER-Power Cord.
Qty: 1 -
NO/VER-Wrench - Torque 8 in/lb, 20 mm open end
Qty: 1 -
LAB/VER-RF Cable Front/REAR Panel Jumper
Qty: 9 -
NO/VER-6 HOLE HANDLE KIT,GREY see #5023-1399 for sub
Qty: 1 -
NO/VER-Keyboard-USB
Qty: 1 -
NO/VER- USB OPT MOUSE (CDW PN# 2086051 @ $7.75/ea)
Qty: 1 -
SW-5969-5826 VNA and PNA Intuilink, E8356-10001 PNA Documentation 12/23/2015, 82357-90002 Manual 82357-90104 Getting Started. N5242-90019 OPT H85 USER AND SVC GUIDE E8356-90001 Installation and Quick Start Guide Edition 2 Aug 2017
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
010, 245
See Configuration Details
-
010
Time Domain For 13.5, 20, 40, And 50 Ghz Pna-L
-
245
300 Khz To 20 Ghz, 4 Port, Configurable Test Set And Extended Power Range
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
NO/VER-Power Cord.
Qty: 1 -
NO/VER-Wrench - Torque 8 in/lb, 20 mm open end
Qty: 1 -
LAB/VER-RF Cable Front/REAR Panel Jumper
Qty: 9 -
NO/VER-6 HOLE HANDLE KIT,GREY see #5023-1399 for sub
Qty: 1 -
NO/VER-Keyboard-USB
Qty: 1 -
NO/VER- USB OPT MOUSE (CDW PN# 2086051 @ $7.75/ea)
Qty: 1 -
SW-5969-5826 VNA and PNA Intuilink, E8356-10001 PNA Documentation 12/23/2015, 82357-90002 Manual 82357-90104 Getting Started. N5242-90019 OPT H85 USER AND SVC GUIDE E8356-90001 Installation and Quick Start Guide Edition 2 Aug 2017
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
