Keysight (Formerly Agilent) N4691A-00F
2-port, 26.5 GHz, 3.5 mm (f) ECal Module
Rent or Lease
The Keysight (formerly Agilent) N4691A MW electronic calibration (ECal) module makes calibration of vector network analyzers fast, easy and accurate. The RF ECal system is now easily controlled by one of two methods depending on the network analyzer. The Keysight (formerly Agilent) PNA and ENA series of network analyzers controls the module directly via the USB interface. The modules can also be controlled via an 85097B interface kit when used with an Keysight (formerly Agilent) 8753E/ES/ET or 8720D/ES/ET. (This requires a special parallel cable and firmware Rev. 7.74).
ECal is an ideal solution for calibrating network analyzers. Performing a full two-port calibration takes less than half the time and number of connections using ECal versus mechanical cal kits. Furthermore, the accuracy of the calibration is comparable between electronic and mechanical methods. Traditional mechanical calibrations require intensive operator interaction which is prone to errors. With ECal, the operator simply connects the ECal module to the network analyzer and the software controls the rest.
Read More
ECal is an ideal solution for calibrating network analyzers. Performing a full two-port calibration takes less than half the time and number of connections using ECal versus mechanical cal kits. Furthermore, the accuracy of the calibration is comparable between electronic and mechanical methods. Traditional mechanical calibrations require intensive operator interaction which is prone to errors. With ECal, the operator simply connects the ECal module to the network analyzer and the software controls the rest.
- Configurations
- Resources
00F
See Configuration Details
-
00F
Female Connector
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
NO/VER- Spanner wrench
Qty: 1 -
NO/VER-Wrench - Torque 8 in/lb, 20 mm open end
Qty: 1 -
NO/VER-Wrench - Torque 8lb-in, 5/16 Inch
Qty: 1 -
NO/VER 1/2" X 9/16" WRENCH
Qty: 1 -
Electronic Calibration Module
Qty: 1 -
LAB/VER-USB A to B cable
Qty: 1 -
NO/VER-Wooden storage box
Qty: 1 -
SW-ECAL Modules Reference Guide June 2015
Qty: 1
